POZONE BS-520 2D DESKTOP BARCODE SCANNER

USB and RS232 interface, can automatically match device, plug and play.

Unique shape design, rotatable base to meet many scanning applications.

Using the most advanced decoding algorithm, can decode most 1D and 2D.

Blue LED indicator, double buzzer to adapt to various nosy environments.

Specifications

OS

Windows

iOS I Android

Image Sensor

CMOS (Global exposure)

lmage (Pixels)

1280(H)*1024 (v)pixels

Light Source

Aiming:617 nm LED

Frame Rate

60fps/s

Scan accuracy

4mil@ Code39

Print Contrast

More than 25%

Visual Indicator

Blue LED Light , USB keyboard,

Buzzer

Scan Angle

Left and right : ± 60 °

Front and rear : ± 65 °

Rotate : 360 °

Field of view

48° horizontal,

30° ver ticaI

Transmission Mode

Wired Transmission

Dimension L x W x H

1S2*76*153 (mm)

Weight

560g  (with cable)

Case Material

ABS+ PC

Power Parameter

Input Voltage : SVDC±S%

Working corrent : 300mA

(Typical value)

Environmental Parameters

Operating Temperature : -20 degree–+ 60 degree

Working Humidity : S% to 95% relative humidity , non-condensing

Storage Temper atur e : -40 degree-+70 degree

Electrostatic protection : ±8 kV (Direct discharge) Ambient brightness : 0-100,000Lux

Drop Resistance : 2M IP : IP52

Safety Regulations

CE (EN 55032:2015;

EN 55035:2017), R  OHS,  BIS,

EN62368-1 :2014+A 11 :2017

FCC PART 15 CL ASS B

Scan Distance

0-200mm @ UPC/EAN 13mil PCS=90%;

0-150mm @ QR 20mil PCS=100%
