POZONE BS-330 BARCODE SCANNER

PERFORMANCE PARAMETER

Sensor: CMOS

PIXEL: 752*480CMOS

Light Source: WHITE LED

Barcode Sensitivity: +50°@0° Roll and 0°Skew +360°@0°Pitch and 0°Skew 30%+60°@0°Roll and 0°Pitch

Contrast: >30%Reflection Difference

Motion Tolerance: 2.5 times/s

Visual Indicator: LED and Buzzer

Reading Accuracy: >5mil

SUPPORTED BARCODE (1D)

CODE 128, UCC/EAN-128, AIM-128, EAN-8, EAN-13, ISBN/ISSN, UPC-E, UPC-A, RSS-EXPAND

Interleaved 2 of15, ITF-G, -14, MATRIX 2 F 4, INDUSTRIAL 25, STANDARD 25, CODE 39, CODABAR

CODABAR, CODE 93, CODE 11, PLESSEY, GSI-DATABASE(RSS), (RSS-14, RSS-LIMITED)

SUPPORTED BARCODE (2D)

PDF417, QR CODE (QR1/2, MICRO), DATA MATRIX (ECC20, ECC000.050,080,100,140)

HANXIN CODE

INTERFACE

USB HID-KBW, USB VIRTUAL SERILA PORT.USB HID-POS.TTL-232

RS-232 INTERFACE

PHYSICAL PARAMETER

WEIGHT: 320g (SCANNING FLATFORM HOST 0NLY)

PROMPT MODE: LIYIN SPEAKER, LED INDICATOR

WORKING CURRENT: 240mA

STAND-BY CURRENT: 190mA

ENVIRONMENTAL PARAMETERS

WORKING TEMPERATURE: -20°C~+50°C

STORAGE TEMPERATURE: -40°C+80°C

RELATED HUMIDITY: 5%~95%(NON-CONDENSING)

DROP HEIGHT: 6 FACE 1.2m concrete floor drops (one on each side)

ELECTROSTATIC PROTECTION: +14kV (AIR DISCHARGE), + 8kV (DIRECT DISCHARGE)

DROP/SHOCK RESISTANCE: WITH STANDS MULTIPLE TIMES 1.2 METER DROPS CONCRETE

PROTECTION LEVEL: IP52

DEPT OF FIELD AND RESOLUTION (1M1L=0.0254MM)

EAN 13: 0c–20cm (13mil)

PDF 417: 0cm-7cm (6.67mil)

Date Matrix: 0cm-4cm (10mil)

QR CODE: 0cm-10 cm (15 mil)

CODE 39: 0cm-12cm (5mil)

CARTON DETAILS

1 CARTON: 58*40*28cm/30pcs/16kgs(box:17.5*13*11cm/1pc/0.5kgs)
